Features:
Environmentally friendly resin is synthesized by lactic acid extracted from corn. Good biocompatibility, lower smell and irritation than other resin.
High toughness, the printed product is not easy to break, easy to process, able to withstand some impact and vibration.
Fast curing speed, good fluidity, low shrinkage, smooth surface and high precision, perfect printing details.
Compatible with 395nm to 405nm wavelength LCD 3D Printers. Widely used in industrial applications, architectural model, jewelry, dental care, toy design, daily design, etc.
Thickened aluminum bottle, not easy to dent, adding inner plug for leakage-free, blocking out the light completely, preserving the resin in good condition.
Specifications:
Brand: eSUN
Type: Bio-based Resin
Color: White/Grey/Black/Skin Color/Transparent(Optional)
Capacity: 500g
Bottle Material: Aluminum
Apply: For LCD 3D Printer
Applicable Wavelength: 395nm to 405nm
Curing Shrinkage: 5.52-5.97%
Density: 1.07 to 1.13 g/cm3
Viscosity (25℃,MPa.s): 200 to 300MPa.s
Tensile Strength: 35-50MPa
Elongation at Break: 20%-50%
Flexural Strength: 40-60MPa
Flexural Modulus: 600-800MPa
Impact Strength of Notch: 15-32j/m
Surface Hardness: 75-80 Shore D
Recommended Print Parameters
Print Layer Thickness: 0.02-0.05mm
Bottom Layer Quantity: 3
Bottom Layer Exposure Time: 30s
Conventional Exposure Time: 6-10s
Note: The exposure time shall be subject to the actual printing effect
Bottle Size: 7.4 * 18.5cm / 2.9 * 7.3in
Package Size: 22 * 12 * 9cm / 8.7 * 4.7 * 3.5in
Package Weight: 630g /22.2oz
Notes:
1. The product is for one-time use and can not be reused.
2. Environmental requirement: It is recommended that ambient temperature be controlled at 20-30℃, to avoid direct light during use, try to isolate children and pregnant women.
3. Wear mask and gloves before use to avoid direct contact with the skin and keep the room ventilated, protective measures should be taken and thoroughly cleaned after operation.
4. Store under cool, shade and dry environment without direct light, recommended storage at room temperature.
5. Shake the resin for 1 to 2 minutes before use to prevent sedimentation.
6. Due to light, screen resolution and other factors, there will be some differences between the actual color and the picture display color of the finished products. Please understand. Thank you.
Packing List:
1 * Bottle Resin Material
